LVBots Challenge 3.5 - Dec 1, 2005
Our sixth robot competition was held back at Jack Lund Schofield Middle School in Las Vegas. We had 28 robots competing in the 6 different events, including our new Walking competetion.
The Best Of Show award went to Bruce Romeo for Disco Boy.
We would like to thank our sponsor for their gracious prize dontations:
 Pololu Robotics |
Line Following Results
We had 13 robots competing in this event.
Robots had to make 3 laps around the track without falling off, and were given 2 chances to do this.
We started with preliminary races to determine the top 4, and then had a single elimination bracket to
pick the winners.
The line following track had 12 straight tiles, and 24 curve tiles, for a total 3 lap length of about 2821 cm.
| Robot | Builder | Best Time | |
| 1st Place | Puck | Paul Grayson | 39.47 seconds |
| 2nd Place | What's That Smell? | Jan Malasek | 42.73 seconds |
| 3rd Place | Laser | Byon Garrabrant | 43.90 seconds |
| 4th Place | Big Ugly | Candice Kamachi | 50.05 seconds |
| Oscar | 59.97 seconds | ||
| No Redeeming Features | 1:00.60 | ||
| Poser | Jan Malasek | 1:02.63 | |
| Van Gogh | Ben Schmidel | 1:53.54 | |
| Anthem | Jamie Gorr | 2:30.09 | |
| Shoe | Byon Garrabrant | DNF | |
| Sled | DNF | ||
| Rod | Bruce Romeo | DNF | |
| Story | DNF |
Mini Sumo Results
We had 4 entrants in the mini sumo event.
The bots were randomly selected for a single elimination bracket of best 2 of 3 battles.
| Robot | Builder | ||
| 1st Place | Ultra Violet | Paul Grayson | |
| 2nd Place | R1 | ||
| 3rd Place | Happy Jr. | Byon Garrabrant | |
| 4th Place | Mr. Happy | Byon Garrabrant |
Walking
We had 4 competitors in our first ever Walking event.
Bots had to walk 3 feet to the edge of a board.
| Robot | Builder | Time | |
| 1st Place | Seis | Byon Garrabrant | 6.45 seconds |
| 2rd Place | WTW | 11.73 seconds | |
| 3rd Place | 4-1 | Paul Grayson | 27.81 seconds |
| Disco Boy | Bruce Romeo | DNF |
Dead Reckoning
We modified our Dead Reckoning contest for this competition to have the bot drive to a line, then follow that line, then return to is starting spot.
| Robot | Builder | ||
| 1st Place | Van Gogh | Ben Schmidel | 7.35" - 1:08.25 |
| 2nd Place | Poser | Jan Malasek | 23" - 49.50 seconds |
| CD Bot | Byon Garrabrant | DNF | |
| Puck | Paul Grayson | DNF |
Line Maze Results
We had 2 competitors in the Line Maze event. See video of CD Bot's second run at
You Tube.
| Robot | Builder | Time | |
| 1st Place | CD Bot | Byon Garrabrant | 35.55 seconds |
| Puck | Paul Grayson | DNF |
Pool Race Results
We only had one entrant, but it was able to handle the course.
| Robot | Builder | ||
| 1st Place | Road Rage | Jan Malasek |
Event pictures
Here are a few pictures from the event.
Road Rage
CD Bot on the Line Maze
Ultra Violet vs Mr. Happy
Puck on the Dead Reckoning course
Pool Boy
4-1
Anthem
Big Ugly vs. Laser
Puck on the Line Following Course
Poser
Rod
Puck
Best of Show Prize
